20 Tons, 36 Station, 1250mm x 2500mm, max sheet size, FANUC 0i-PC Control
VISE1250 CNC Punch Press
|
Model
|
VISE1250
|
|
|
Punch Capacity
|
tons
|
20
|
|
Traverse Length X x Y
|
mm
|
1250 x 1250
|
|
Max Sheet Size
|
mm
|
1250 x 2500
|
|
Max Sheet Thickness
|
mm
|
6.35
|
|
Max Sheet Weight
|
kg
|
110
|
|
Traverse Axis Speed
X x Y |
m/min
|
55 x 50
|
|
Tooling Type
|
Thick Turret
|
|
|
25mm between Holes
|
m/min
|
210
|
|
Nibbling Speed
|
m/min
|
350
|
|
Max Punch Diameter
|
mm
|
88.9
|
|
Number of Stations
|
36
|
|
|
Number of Auto Index Stations
|
2 x B type
|
|
|
Turret Rotation
|
rpm
|
40
|
|
Auto Index Rotation
|
rpm
|
|
|
Ram Stroke Length
|
mm
|
32
|
|
Number of Sheet Clamps
|
2
|
|
|
Power Requirement
|
kva
|
20
|
|
Air Consumption
|
L/min
|
250
|
|
Required Air Pressure
|
bar
|
5
|
|
Oil Tank Volume
|
L
|
120
|
|
Machine Size
L x W x H |
mm
|
4395x2630x2245
|
|
Controller Cabinet
W x D x H |
mm
|
1200x 600x1900
|
|
CNC Controller
|
FANUC 0i-PC
|
|
|
Memory
|
kb
|
256
|
|
Number of Controllable Axes
|
4
|
(1) The speed of X and Y axes depend upon the weight of the work sheet.
(2) The punch speed depends upon the length and speed of ram stroke and the speed of X and Y axes.
(2) The punch speed depends upon the length and speed of ram stroke and the speed of X and Y axes.
| Size | 3.0-4.5 Dl |
|---|
PART #
Vise1250
